1) Program data obtained in conformity with European standard EN 50242, obtained under normal conditions (without any options) and may vary depending on conditions. Differences of up to
20 minutes are possible with sensor programs as a result of the appliance’s automatic calibration system.
2) Reference program for energy label in compliance with EN 50242 regulations. - Note for Testing Institutes: for detailed information on the EN/Standard loading comparison test and other tests, contact the following
address: “nk_customer@whirlpool.com”.
3) The antibacterial action has been tested by the Institut Pasteur of Lille (France), based on the NF EN 13697 standard of November 2001.
Table of programs
Deter-
gent
Consumption
Drying
Phase
Programs
Available
options
Loading instructions
Litres kWh
Minutes
1)
P1
6th Sense Power
Clean
40-70°C
Delay
Multizone
Power Clean
Use for normal soiled dishes with dried-on food. Senses the
level of soiling on the dishes and adjusts the program
accordingly. When the sensor is detecting the soil level an
animation appears in the display and the cycle duration is
updated. The Power Clean option is activated automatically
with this program. To deactivate, press the Power Clean
button on the control panel.
X 7-14 1.00-1.65 80-165 Full
P2
Pre Wash cold
Delay
Multizone
Crockery to be washed later. — 4.0 0.03 14 NO
P3
Fragile 40°C
Delay
Multizone
Light soiling, for example glasses and cups. X 10.0 0.85 100 Light
P4
Rapid 45°C
Delay
Multizone
Lightly soiled crockery, with no dried-on food. X 11.0 0.80 30 NO
P5
Eco
2)
50°C
Delay
Multizone
Power Clean
Normally soiled crockery. Energy-saving program. X 11.5 0.93 240 Full
P6
Fast Daily 60°C
Delay
Multizone
Normally soiled crockery. X 10.0 1.30 80 Full
P7
Silent 50°C
Delay
Multizone
Normally soiled crockery, gentle and quiet thanks to the
lower spray pressure (39 dbA).
X 13.0 1.20 290 Light
P8
Intensive 65°C
Delay
Multizone
Power Clean
Recommended program for heavily soiled crockery,
especially suitable for pans and saucepans.
X 14.0 1.60 145 Full
P9
Steam
Delay
Multizone
Power Clean
Program including steam action dedicated for heavily soiled
crockery, pots and pans. Soaking or hand pretreatment is no
longer needed.
X 14.0 1.70 180 Full
P10
Hygiene
3)
Delay
Multizone
Power Clean
Normally or heavily soiled crockery, with additional
antibacterial wash. Program interruption (e.g. due to door
opening) can compromise elimination of germs.
X 13.0 1.50 118 Full
